Featured Products

•

  Split-Type Tube Furnaces for Horizontal or Vertical Operation up to 1300 °C

  Details Share

  Share on:

  facebook

  twitter

  google

  pinterest

  These tube furnaces can be used for horizontal (RSH) or vertical (RSV) operation. The split-type design makes it easy to change the working tube. It allows
  for a comfortable exchange of various working tubes (e.g. working tubes made of different materials).
  Using a wide range of accessories, these professional tube furnaces can be optimally tailored for your process. By adding different gas supply packages,
  you can work in a protective gas atmosphere, with gases or in a vacuum. In addition to the convenient standard controllers, modern PLC controls can also
  be used to control the process.

  Standard Equipment
  · Tmax 1100 °C or 1300 °C
  · Single-zoned design
  · RSV models with frame for vertical operation
  · Split-type design for simple insertion of the working tube (opening temperature
  < 180 °C)
  · Ceramic working tube C 530 including two fiber plugs for operation under air see
  page 56
  · Thermocouple type N (1100 °C) or type S (1300 °C)
  · Heating elements on support tubes provide for free radiation
  · RSH: switchgear and control unit integrated in furnace housing
  · RSV: switchgear and control unit separate from furnace in own wall or standing
  cabinet
  · Controller B410, alternative controllers

  Additional Equipment
  · Charge control with temperature measurement in the working tube
  · Three-zone control for optimization of temperature uniformity
  · Alternative working tubes
  · Cooling systems for accelerated cooling of the working tube and charge
  · Gas supply systems 1,15 or 2 for non-flammable protective or reactive gas
  operation
  · Gas supply packages 3 or 4 for hydrogen operation
  · Vacuum package to evacuate the working tube

  Details
•

  High-Temperature Furnaces with SiC Rod Heating up to 1550 °C

  Details Share

  Share on:

  facebook

  twitter

  google

  pinterest

  The high-temperature furnaces HTC 16/16 – HTC 450/16 are heated by vertically hung SiC rods, which makes them especially suitable for sintering
  processes up to a maximum operating temperature of 1550 °C. For some processes, e.g. for sintering zirconium oxide, the absence of interactivity
  between the charge and the SiC rods, these models are more suitable than the alternatives heated with molybdenum disilicide elements. The basic
  construction of these furnaces make them comparable with the already familiar models in the HT product line and they can be upgraded with the same
  additional equipment.

  Standard Equipment

  ·Tmax 1550 °C
  · Dual shell housing with fan cooling for low shell temperatures
  · Heating from both sides via vertically mounted SiC rods
  · High-quality fiber insulation backed by special insulation
  · Side insulation constructed with tongue and groove blocks provides for low heat
  loss to the outside
  · Long-life roof insulation with special suspension
  · Chain-guided parallel swivel door for defined opening and closing of the door
  without destroying the insulation
  · Two-door design (front/back) for high-temperature furnaces > HTC 276/..
  · Labyrinth sealing ensures the least possible temperature loss in the door area
  · Reinforced floor as protection for bottom insulation
  · Vapor vent in the furnace roof with motorized exhaust air flaps, controlled via the
  extra function of the controller
  · Heating elements switched via SCR‘s
  · Over-temperature limiter with adjustable cutout temperature as temperature
  limiter to protect the oven and load

  Details
•

  High-temperature furnace LHT 04/16 SW with scale for measuring weight reduction during annealing

  Details Share

  Share on:

  facebook

  twitter

  google

  pinterest

  These high-temperature furnaces were specially developed to determine combustion loss during annealing and for thermogravimetric analysis (TGA) in
  the lab. The complete system consists of the high-temperature furnace for 1600 °C or 1750 °C, a table frame, precision scale with feedthroughs into the
  furnace and powerful software for recording both the temperature curve and the weight loss over time.

  Standard Equipment
  · Tmax 1600 °C or 1750 °C
  · High-quality molybdenum disilicide heating elements
  · Dual shell housing made of textured stainless steel sheets with additional fan cooling
  for low surface temperature
  · Adjustable air inlet
  · Exhaust air opening in the roof
  · Type B thermocouple
  · Delivery includes base, ceramic plunger with base plate in the furnace lining,
  precision scale and software package
  · 4 scales available for different maximum weights and scaling ranges
  · Process control and documentation for temperature and combustion loss via
  VCD software package for monitoring, documentation and control

  Details
•

  Chamber furnace N 61/H for Annealing, Hardening and Brazing up to 1280 °C

  Details Share

  Share on:

  facebook

  twitter

  google

  pinterest

  To withstand harsh use in the laboratory, e.g. when heat-treating metals, robust insulation with light refractory bricks is necessary. The chamber furnaces
  N 7/H – N 87/H are a perfect fit to solve this problem. The furnaces can be extended with a variety of accessories, like annealing boxes for operation
  under protective gas, roller guides, or a cooling station with a quench tank. Even high-performance applications like the annealing of titanium in medical
  applications can be implemented without the use of expensive and complicated annealing systems.

  Standard Equipment
  · Tmax 1280 °C
  · Deep furnace chamber with three-sides heating: from both side walls and bottom
  · Heating elements on support tubes ensure free heat radiation and a long service
  life
  · Bottom heating protected by heat-resistant SiC plate
  · Temperature uniformity up to +/− 10 °C according to DIN 17052-1
  · Low energy consumption due to multi-layer insulation
  · Base frame included in the delivery, N 7/H – N 17/HR designed as table-top
  model
  · Parallel guided downward swinging door (user protected from heat radiation)
  · Door movement cushioned with gas dampers/struts
  · Controller B400 (5 prgrams with each 4 segments)

  Details
•

  Ashing Furnaces up to 1100 °C

  Details Share

  Share on:

  facebook

  twitter

  google

  pinterest

  Ashing furnace LV ../11 is designed especially for ashing processes to 1050 °C in the laboratory. Applications include determining loss on ignition, ashing
  food and plastics for subsequent substance analysis. A special fresh-air and exhaust air system ensures that the air is replaced 6 times per minute so that
  there is always sufficient oxygen for the ashing process. Incoming air passes the furnace heating and is pre-heated to ensure good temperature uniformity.

  Standard Equipment
  · Tmax 1100 °C
  · Heating from two sides
  · Ceramic heating plates with integral heating element which is safeguarded, and
  easy to replace
  · Air exchange of more than 6 times per minute
  · Good temperature uniformity due to preheating of incoming air, temperature
  uniformity according to DIN 17052-1 to +/− 10 °C in the defined empty work area
  (from 550 °C)
  · Suitable for many standardized ashing processes according to ISO, ASTM, EN,
  and DIN
  · Optional flap door (LV) which can be used as work platform or lift door (LVT) with
  hot surface facing away from the operator
  · Controller B410 (5 programs with each 4 segments), alternative controllers



  Additional Equipment
  · Over-temperature limiter with adjustable cutout temperature as temperature
  limiter to protect the oven and load
  · Port for thermocouple in the rear wall or in the furnace door
  · Charging rack with closed or perforated trays for loading the furnace in two
  levels incl. holder for inserting/removing the trays up to a max. temperature of 800°C and a max. loading weight of 2 kg for the LV(T) 9/11 respectively 3 kg for
  the LV(T) 15/11

  Details
•

  High-Temperature Furnaces with Molybdenum Disilicide Heating Elements with Fiber Insulation up to 1800 °C

  Details Share

  Share on:

  facebook

  twitter

  google

  pinterest

  Due to their solid construction and compact stand-alone design, these high-temperature furnaces are perfect for processes in the laboratory where
  the highest precision is needed. Oustanding temperature uniformity and practical details set very high quality benchmarks. For configuration for your
  processes, these furnaces can be extended with extras from our extensive option list.

  Standard Equipment
  · Tmax 1600 °C, 1750 °C, or 1800 °C
  · Recommended working temperature 1750 °C (for models HT ../18), increased
  wear and tear must be expected in case of working at higher temperatures
  · Dual shell housing with fan cooling for low shell temperatures
  · Heating from both sides via molybdenum disilicide heating elements
  · High-quality fiber insulation backed by special insulation
  · Side insulation constructed with tongue and groove blocks provides for low heat
  loss to the outside
  · Long-life roof insulation with special suspension
  · Chain-guided parallel swivel door for defined opening and closing of the door
  · Two-door design (front/back) for high-temperature furnaces from HT 276/..
  · Labyrinth sealing ensures the least possible temperature loss in the door area
  · Reinforced floor as protection for bottom insulation as standard from models
  HT 16/16 upwards (distributed load 5 kg/dm2)
  · Vapor vent in the furnace roof with motorized exhaust air flaps, controlled via the
  extra function of the controller
  · Heating elements switched via thyristors

  Additional Equipment
  · Cooling system to cool the furnace with a defined temperature gradient or with
  a preset fresh air volume. Both operating modes can be switched on and off for
  different segments by means of the extra function of the controller.
  · Safety package for debinding in air. Debinding technical ceramics is a critical
  process because of the hydrocarbons that are released. Hydrocarbons are
  flammable and there is a risk that a flammable mixture could form inside the
  furnace. Nabertherm offers tailored safety packages with respect to the process
  and the volume of binder that allow the furnace to be operated safely.
  · Special heating elements for zirconia sintering
  · Protective gas connection to purge with non-flammable protective or reaction
  gases
  · Automatic gas supply system with solenoid valve and rotameter, controlled by
  the extra function of the controller
  · Inner process box to improve the gas tightness and to protect the furnace
  chamber against contamination
  · Refractory brick floor insulation for a higher floor load (Tmax 1700 °C)
  · Lift door
  · Automatic door lock incl. door contact switch
  · Ethernet interface



  Details
•

  High-Temperature Furnaces with MoSi2 Heating Elements up to 1800 °C

  Details Share

  Share on:

  facebook

  twitter

  google

  pinterest

  Designed as tabletop models, these compact high-temperature furnaces have a variety of advantages. The first-class workmanship using high-quality
  materials, combined with ease of operation, make these furnaces all-rounders in research and the laboratory. These high-temperature furnaces are also
  perfectly suited for the sintering of technical ceramics, such as zirconium oxide dental bridges.

  Standard Equipment
  · Tmax 1600 °C, 1750 °C, or 1800 °C
  · Recommended working temperature 1750 °C (for models LHT ../18), increased
  wear and tear must be expected in case of working at higher temperatures
  · High-quality molybdenum disilicide heating elements
  · Adjustable air inlet opening, exhaust air opening in the roof
  · Type B thermocouple
  · Controller P470 (50 programs with each 40 segments), controls description see
  page 75

  Additional Equipment
  · Over-temperature limiter with adjustable cutout temperature as temperature
  limiter to protect the oven and load
  · Protective gas connection to purge with non-flammable protective or reaction
  gases, not gas tight
  · Manual or automatic gas supply system

  Details
•

  High-temperature furnace LHTCT 01/16

  Details Share

  Share on:

  facebook

  twitter

  google

  pinterest

  These powerful laboratory muffle furnaces are available for temperatures up to 1400 °C, 1500 °C, 1550 °C or 1600 °C. The durability of the SiC rods in
  periodic use, in combination with their high heating speed, make these high-temperature furnaces to all-rounders in the laboratory. Heating times of
  20 – 25 minutes to 1400 °C can be achieved, depending on the furnace model and the conditions of use.

  Standard Equipment
  · Tmax 1400 °C, 1500 °C, 1550 °C or 1600 °C
  · Working temperature 1500 °C (for high-temperature furnaces LHTC ../16),
  increased wear and tear must be expected in case of working at higher
  temperatures
  · Optional flap door (LHTC) which can be used as work platform or lift door
  (LHTCT) with hot surface facing away from the operator (High-temperature
  furnace LHTCT 01/16 only with lift door)
  · Switching system with solid-state-relays, power tuned to the SiC rods
  · Easy replacement of heating rods
  · Adjustable air inlet opening, exhaust air opening in the roof
  · Controller C450 (10 programs with each 20 segments), alternative controllers

  Additional Equipment
  · Over-temperature limiter with adjustable cutout temperature as temperature
  limiter to protect the oven and load
  · Protective gas connection to purge with non-flammable protective or reaction
  gases, not gas tight
  · Manual or automatic gas supply system

  Details
