With their maximum working temperature of up to 300 °C and forced air circulation, the ovens achieve a very good temperature uniformity. They can be used for various applications such as e.g. drying, sterilizing or warm storing. Short delivery times from stock are ensured for standard models.

Standard Equipment

• Tmax 300 °C
• Working temperature range: + 20 °C above room temperature up to 300 °C
• Ovens TR 120 designed as tabletop models
• Horizontal forced air circulation results in temperature uniformity according to DIN 17052-1 better than +/− 5 °C in the empty oven (with closed exhaust air flap)
• Stainless steel furnace housing, material no. 1.4016 (DIN)
• Stainless steel chamber, alloy 304 (AISI)/(DIN material no. 1.4301), rust-resistant and easy to clean
• Exclusive use of insulation materials without categorization according to EC Regulation No 1272/2008 (CLP). This explicitly means that alumino silicate wool, also known as “refractory ceramic fiber” (RCF), which is classified and possibly carcinogenic, is not used.
• Charging in multiple layers possible using removeable grids (number of removeable grids included, see table)
• Large, wide-opening swing door, hinged on the right with quick release for models TR 30 – TR 240 and TR 450
• Double swing door with quick release for models TR 420, TR 800 and TR 1050
• Ovens TR 800 and TR 1050 equipped with transport castors
• Infinitely adjustable exhaust at the rear wall with operation from the front
• PID microprocessor control with self-diagnosis system
• Models TR .. LS: Safety technology according to EN 1539 for charges containing liquid solvents, achievable temperature uniformity +/− 8 °C according to DIN 17052-1 in the empty oven (with closed exhaust air flap)
• Controller R7 (resp. C550 for TR ..LS)
• Solid state relays provide for lownoise operation
• Defined application within the constraints of the operating instructions
• NTLog Basic for Nabertherm controller: recording of process data with USB-flash drive
