Details
These tube furnaces can be used for horizontal (RSH) or vertical (RSV) operation. The split-type design makes it easy to change the working tube. It allows
for a comfortable exchange of various working tubes (e.g. working tubes made of different materials).
Using a wide range of accessories, these professional tube furnaces can be optimally tailored for your process. By adding different gas supply packages,
you can work in a protective gas atmosphere, with gases or in a vacuum. In addition to the convenient standard controllers, modern PLC controls can also
be used to control the process.Standard Equipment
· Tmax 1100 °C or 1300 °C
· Single-zoned design
· RSV models with frame for vertical operation
· Split-type design for simple insertion of the working tube (opening temperature
< 180 °C)
· Ceramic working tube C 530 including two fiber plugs for operation under air see
page 56
· Thermocouple type N (1100 °C) or type S (1300 °C)
· Heating elements on support tubes provide for free radiation
· RSH: switchgear and control unit integrated in furnace housing
· RSV: switchgear and control unit separate from furnace in own wall or standing
cabinet
· Controller B410, alternative controllersAdditional Equipment
· Charge control with temperature measurement in the working tube
· Three-zone control for optimization of temperature uniformity
· Alternative working tubes
· Cooling systems for accelerated cooling of the working tube and charge
· Gas supply systems 1,15 or 2 for non-flammable protective or reactive gas
operation
· Gas supply packages 3 or 4 for hydrogen operation
· Vacuum package to evacuate the working tube -
Details
The high-temperature furnaces HTC 16/16 – HTC 450/16 are heated by vertically hung SiC rods, which makes them especially suitable for sintering
processes up to a maximum operating temperature of 1550 °C. For some processes, e.g. for sintering zirconium oxide, the absence of interactivity
between the charge and the SiC rods, these models are more suitable than the alternatives heated with molybdenum disilicide elements. The basic
construction of these furnaces make them comparable with the already familiar models in the HT product line and they can be upgraded with the same
additional equipment.Standard Equipment
·Tmax 1550 °C
· Dual shell housing with fan cooling for low shell temperatures
· Heating from both sides via vertically mounted SiC rods
· High-quality fiber insulation backed by special insulation
· Side insulation constructed with tongue and groove blocks provides for low heat
loss to the outside
· Long-life roof insulation with special suspension
· Chain-guided parallel swivel door for defined opening and closing of the door
without destroying the insulation
· Two-door design (front/back) for high-temperature furnaces > HTC 276/..
· Labyrinth sealing ensures the least possible temperature loss in the door area
· Reinforced floor as protection for bottom insulation
· Vapor vent in the furnace roof with motorized exhaust air flaps, controlled via the
extra function of the controller
· Heating elements switched via SCR‘s
· Over-temperature limiter with adjustable cutout temperature as temperature
limiter to protect the oven and load -
Details
These high-temperature furnaces were specially developed to determine combustion loss during annealing and for thermogravimetric analysis (TGA) in
the lab. The complete system consists of the high-temperature furnace for 1600 °C or 1750 °C, a table frame, precision scale with feedthroughs into the
furnace and powerful software for recording both the temperature curve and the weight loss over time.Standard Equipment
· Tmax 1600 °C or 1750 °C
· High-quality molybdenum disilicide heating elements
· Dual shell housing made of textured stainless steel sheets with additional fan cooling
for low surface temperature
· Adjustable air inlet
· Exhaust air opening in the roof
· Type B thermocouple
· Delivery includes base, ceramic plunger with base plate in the furnace lining,
precision scale and software package
· 4 scales available for different maximum weights and scaling ranges
· Process control and documentation for temperature and combustion loss via
VCD software package for monitoring, documentation and control -
Details
To withstand harsh use in the laboratory, e.g. when heat-treating metals, robust insulation with light refractory bricks is necessary. The chamber furnaces
N 7/H – N 87/H are a perfect fit to solve this problem. The furnaces can be extended with a variety of accessories, like annealing boxes for operation
under protective gas, roller guides, or a cooling station with a quench tank. Even high-performance applications like the annealing of titanium in medical
applications can be implemented without the use of expensive and complicated annealing systems.Standard Equipment
· Tmax 1280 °C
· Deep furnace chamber with three-sides heating: from both side walls and bottom
· Heating elements on support tubes ensure free heat radiation and a long service
life
· Bottom heating protected by heat-resistant SiC plate
· Temperature uniformity up to +/− 10 °C according to DIN 17052-1
· Low energy consumption due to multi-layer insulation
· Base frame included in the delivery, N 7/H – N 17/HR designed as table-top
model
· Parallel guided downward swinging door (user protected from heat radiation)
· Door movement cushioned with gas dampers/struts
· Controller B400 (5 prgrams with each 4 segments) -
Details
Ashing furnace LV ../11 is designed especially for ashing processes to 1050 °C in the laboratory. Applications include determining loss on ignition, ashing
food and plastics for subsequent substance analysis. A special fresh-air and exhaust air system ensures that the air is replaced 6 times per minute so that
there is always sufficient oxygen for the ashing process. Incoming air passes the furnace heating and is pre-heated to ensure good temperature uniformity.Standard Equipment
· Tmax 1100 °C
· Heating from two sides
· Ceramic heating plates with integral heating element which is safeguarded, and
easy to replace
· Air exchange of more than 6 times per minute
· Good temperature uniformity due to preheating of incoming air, temperature
uniformity according to DIN 17052-1 to +/− 10 °C in the defined empty work area
(from 550 °C)
· Suitable for many standardized ashing processes according to ISO, ASTM, EN,
and DIN
· Optional flap door (LV) which can be used as work platform or lift door (LVT) with
hot surface facing away from the operator
· Controller B410 (5 programs with each 4 segments), alternative controllersAdditional Equipment
· Over-temperature limiter with adjustable cutout temperature as temperature
limiter to protect the oven and load
· Port for thermocouple in the rear wall or in the furnace door
· Charging rack with closed or perforated trays for loading the furnace in two
levels incl. holder for inserting/removing the trays up to a max. temperature of 800°C and a max. loading weight of 2 kg for the LV(T) 9/11 respectively 3 kg for
the LV(T) 15/11 -
Details
Due to their solid construction and compact stand-alone design, these high-temperature furnaces are perfect for processes in the laboratory where
the highest precision is needed. Oustanding temperature uniformity and practical details set very high quality benchmarks. For configuration for your
processes, these furnaces can be extended with extras from our extensive option list.Standard Equipment
· Tmax 1600 °C, 1750 °C, or 1800 °C
· Recommended working temperature 1750 °C (for models HT ../18), increased
wear and tear must be expected in case of working at higher temperatures
· Dual shell housing with fan cooling for low shell temperatures
· Heating from both sides via molybdenum disilicide heating elements
· High-quality fiber insulation backed by special insulation
· Side insulation constructed with tongue and groove blocks provides for low heat
loss to the outside
· Long-life roof insulation with special suspension
· Chain-guided parallel swivel door for defined opening and closing of the door
· Two-door design (front/back) for high-temperature furnaces from HT 276/..
· Labyrinth sealing ensures the least possible temperature loss in the door area
· Reinforced floor as protection for bottom insulation as standard from models
HT 16/16 upwards (distributed load 5 kg/dm2)
· Vapor vent in the furnace roof with motorized exhaust air flaps, controlled via the
extra function of the controller
· Heating elements switched via thyristorsAdditional Equipment
· Cooling system to cool the furnace with a defined temperature gradient or with
a preset fresh air volume. Both operating modes can be switched on and off for
different segments by means of the extra function of the controller.
· Safety package for debinding in air. Debinding technical ceramics is a critical
process because of the hydrocarbons that are released. Hydrocarbons are
flammable and there is a risk that a flammable mixture could form inside the
furnace. Nabertherm offers tailored safety packages with respect to the process
and the volume of binder that allow the furnace to be operated safely.
· Special heating elements for zirconia sintering
· Protective gas connection to purge with non-flammable protective or reaction
gases
· Automatic gas supply system with solenoid valve and rotameter, controlled by
the extra function of the controller
· Inner process box to improve the gas tightness and to protect the furnace
chamber against contamination
· Refractory brick floor insulation for a higher floor load (Tmax 1700 °C)
· Lift door
· Automatic door lock incl. door contact switch
· Ethernet interface -
Details
Designed as tabletop models, these compact high-temperature furnaces have a variety of advantages. The first-class workmanship using high-quality
materials, combined with ease of operation, make these furnaces all-rounders in research and the laboratory. These high-temperature furnaces are also
perfectly suited for the sintering of technical ceramics, such as zirconium oxide dental bridges.Standard Equipment
· Tmax 1600 °C, 1750 °C, or 1800 °C
· Recommended working temperature 1750 °C (for models LHT ../18), increased
wear and tear must be expected in case of working at higher temperatures
· High-quality molybdenum disilicide heating elements
· Adjustable air inlet opening, exhaust air opening in the roof
· Type B thermocouple
· Controller P470 (50 programs with each 40 segments), controls description see
page 75Additional Equipment
· Over-temperature limiter with adjustable cutout temperature as temperature
limiter to protect the oven and load
· Protective gas connection to purge with non-flammable protective or reaction
gases, not gas tight
· Manual or automatic gas supply system -
Details
These powerful laboratory muffle furnaces are available for temperatures up to 1400 °C, 1500 °C, 1550 °C or 1600 °C. The durability of the SiC rods in
periodic use, in combination with their high heating speed, make these high-temperature furnaces to all-rounders in the laboratory. Heating times of
20 – 25 minutes to 1400 °C can be achieved, depending on the furnace model and the conditions of use.Standard Equipment
· Tmax 1400 °C, 1500 °C, 1550 °C or 1600 °C
· Working temperature 1500 °C (for high-temperature furnaces LHTC ../16),
increased wear and tear must be expected in case of working at higher
temperatures
· Optional flap door (LHTC) which can be used as work platform or lift door
(LHTCT) with hot surface facing away from the operator (High-temperature
furnace LHTCT 01/16 only with lift door)
· Switching system with solid-state-relays, power tuned to the SiC rods
· Easy replacement of heating rods
· Adjustable air inlet opening, exhaust air opening in the roof
· Controller C450 (10 programs with each 20 segments), alternative controllersAdditional Equipment
· Over-temperature limiter with adjustable cutout temperature as temperature
limiter to protect the oven and load
· Protective gas connection to purge with non-flammable protective or reaction
gases, not gas tight
· Manual or automatic gas supply system
-
Details
These tube furnaces can be used for horizontal (RSH) or vertical (RSV) operation. The split-type design makes it easy to change the working tube. It allows
for a comfortable exchange of various working tubes (e.g. working tubes made of different materials).
Using a wide range of accessories, these professional tube furnaces can be optimally tailored for your process. By adding different gas supply packages,
you can work in a protective gas atmosphere, with gases or in a vacuum. In addition to the convenient standard controllers, modern PLC controls can also
be used to control the process.Standard Equipment
· Tmax 1100 °C or 1300 °C
· Single-zoned design
· RSV models with frame for vertical operation
· Split-type design for simple insertion of the working tube (opening temperature
< 180 °C)
· Ceramic working tube C 530 including two fiber plugs for operation under air see
page 56
· Thermocouple type N (1100 °C) or type S (1300 °C)
· Heating elements on support tubes provide for free radiation
· RSH: switchgear and control unit integrated in furnace housing
· RSV: switchgear and control unit separate from furnace in own wall or standing
cabinet
· Controller B410, alternative controllersAdditional Equipment
· Charge control with temperature measurement in the working tube
· Three-zone control for optimization of temperature uniformity
· Alternative working tubes
· Cooling systems for accelerated cooling of the working tube and charge
· Gas supply systems 1,15 or 2 for non-flammable protective or reactive gas
operation
· Gas supply packages 3 or 4 for hydrogen operation
· Vacuum package to evacuate the working tube -
Details
The high-temperature furnaces HTC 16/16 – HTC 450/16 are heated by vertically hung SiC rods, which makes them especially suitable for sintering
processes up to a maximum operating temperature of 1550 °C. For some processes, e.g. for sintering zirconium oxide, the absence of interactivity
between the charge and the SiC rods, these models are more suitable than the alternatives heated with molybdenum disilicide elements. The basic
construction of these furnaces make them comparable with the already familiar models in the HT product line and they can be upgraded with the same
additional equipment.Standard Equipment
·Tmax 1550 °C
· Dual shell housing with fan cooling for low shell temperatures
· Heating from both sides via vertically mounted SiC rods
· High-quality fiber insulation backed by special insulation
· Side insulation constructed with tongue and groove blocks provides for low heat
loss to the outside
· Long-life roof insulation with special suspension
· Chain-guided parallel swivel door for defined opening and closing of the door
without destroying the insulation
· Two-door design (front/back) for high-temperature furnaces > HTC 276/..
· Labyrinth sealing ensures the least possible temperature loss in the door area
· Reinforced floor as protection for bottom insulation
· Vapor vent in the furnace roof with motorized exhaust air flaps, controlled via the
extra function of the controller
· Heating elements switched via SCR‘s
· Over-temperature limiter with adjustable cutout temperature as temperature
limiter to protect the oven and load -
Details
These high-temperature furnaces were specially developed to determine combustion loss during annealing and for thermogravimetric analysis (TGA) in
the lab. The complete system consists of the high-temperature furnace for 1600 °C or 1750 °C, a table frame, precision scale with feedthroughs into the
furnace and powerful software for recording both the temperature curve and the weight loss over time.Standard Equipment
· Tmax 1600 °C or 1750 °C
· High-quality molybdenum disilicide heating elements
· Dual shell housing made of textured stainless steel sheets with additional fan cooling
for low surface temperature
· Adjustable air inlet
· Exhaust air opening in the roof
· Type B thermocouple
· Delivery includes base, ceramic plunger with base plate in the furnace lining,
precision scale and software package
· 4 scales available for different maximum weights and scaling ranges
· Process control and documentation for temperature and combustion loss via
VCD software package for monitoring, documentation and control -
Details
To withstand harsh use in the laboratory, e.g. when heat-treating metals, robust insulation with light refractory bricks is necessary. The chamber furnaces
N 7/H – N 87/H are a perfect fit to solve this problem. The furnaces can be extended with a variety of accessories, like annealing boxes for operation
under protective gas, roller guides, or a cooling station with a quench tank. Even high-performance applications like the annealing of titanium in medical
applications can be implemented without the use of expensive and complicated annealing systems.Standard Equipment
· Tmax 1280 °C
· Deep furnace chamber with three-sides heating: from both side walls and bottom
· Heating elements on support tubes ensure free heat radiation and a long service
life
· Bottom heating protected by heat-resistant SiC plate
· Temperature uniformity up to +/− 10 °C according to DIN 17052-1
· Low energy consumption due to multi-layer insulation
· Base frame included in the delivery, N 7/H – N 17/HR designed as table-top
model
· Parallel guided downward swinging door (user protected from heat radiation)
· Door movement cushioned with gas dampers/struts
· Controller B400 (5 prgrams with each 4 segments) -
Details
Ashing furnace LV ../11 is designed especially for ashing processes to 1050 °C in the laboratory. Applications include determining loss on ignition, ashing
food and plastics for subsequent substance analysis. A special fresh-air and exhaust air system ensures that the air is replaced 6 times per minute so that
there is always sufficient oxygen for the ashing process. Incoming air passes the furnace heating and is pre-heated to ensure good temperature uniformity.Standard Equipment
· Tmax 1100 °C
· Heating from two sides
· Ceramic heating plates with integral heating element which is safeguarded, and
easy to replace
· Air exchange of more than 6 times per minute
· Good temperature uniformity due to preheating of incoming air, temperature
uniformity according to DIN 17052-1 to +/− 10 °C in the defined empty work area
(from 550 °C)
· Suitable for many standardized ashing processes according to ISO, ASTM, EN,
and DIN
· Optional flap door (LV) which can be used as work platform or lift door (LVT) with
hot surface facing away from the operator
· Controller B410 (5 programs with each 4 segments), alternative controllersAdditional Equipment
· Over-temperature limiter with adjustable cutout temperature as temperature
limiter to protect the oven and load
· Port for thermocouple in the rear wall or in the furnace door
· Charging rack with closed or perforated trays for loading the furnace in two
levels incl. holder for inserting/removing the trays up to a max. temperature of 800°C and a max. loading weight of 2 kg for the LV(T) 9/11 respectively 3 kg for
the LV(T) 15/11 -
Details
Due to their solid construction and compact stand-alone design, these high-temperature furnaces are perfect for processes in the laboratory where
the highest precision is needed. Oustanding temperature uniformity and practical details set very high quality benchmarks. For configuration for your
processes, these furnaces can be extended with extras from our extensive option list.Standard Equipment
· Tmax 1600 °C, 1750 °C, or 1800 °C
· Recommended working temperature 1750 °C (for models HT ../18), increased
wear and tear must be expected in case of working at higher temperatures
· Dual shell housing with fan cooling for low shell temperatures
· Heating from both sides via molybdenum disilicide heating elements
· High-quality fiber insulation backed by special insulation
· Side insulation constructed with tongue and groove blocks provides for low heat
loss to the outside
· Long-life roof insulation with special suspension
· Chain-guided parallel swivel door for defined opening and closing of the door
· Two-door design (front/back) for high-temperature furnaces from HT 276/..
· Labyrinth sealing ensures the least possible temperature loss in the door area
· Reinforced floor as protection for bottom insulation as standard from models
HT 16/16 upwards (distributed load 5 kg/dm2)
· Vapor vent in the furnace roof with motorized exhaust air flaps, controlled via the
extra function of the controller
· Heating elements switched via thyristorsAdditional Equipment
· Cooling system to cool the furnace with a defined temperature gradient or with
a preset fresh air volume. Both operating modes can be switched on and off for
different segments by means of the extra function of the controller.
· Safety package for debinding in air. Debinding technical ceramics is a critical
process because of the hydrocarbons that are released. Hydrocarbons are
flammable and there is a risk that a flammable mixture could form inside the
furnace. Nabertherm offers tailored safety packages with respect to the process
and the volume of binder that allow the furnace to be operated safely.
· Special heating elements for zirconia sintering
· Protective gas connection to purge with non-flammable protective or reaction
gases
· Automatic gas supply system with solenoid valve and rotameter, controlled by
the extra function of the controller
· Inner process box to improve the gas tightness and to protect the furnace
chamber against contamination
· Refractory brick floor insulation for a higher floor load (Tmax 1700 °C)
· Lift door
· Automatic door lock incl. door contact switch
· Ethernet interface -
Details
Designed as tabletop models, these compact high-temperature furnaces have a variety of advantages. The first-class workmanship using high-quality
materials, combined with ease of operation, make these furnaces all-rounders in research and the laboratory. These high-temperature furnaces are also
perfectly suited for the sintering of technical ceramics, such as zirconium oxide dental bridges.Standard Equipment
· Tmax 1600 °C, 1750 °C, or 1800 °C
· Recommended working temperature 1750 °C (for models LHT ../18), increased
wear and tear must be expected in case of working at higher temperatures
· High-quality molybdenum disilicide heating elements
· Adjustable air inlet opening, exhaust air opening in the roof
· Type B thermocouple
· Controller P470 (50 programs with each 40 segments), controls description see
page 75Additional Equipment
· Over-temperature limiter with adjustable cutout temperature as temperature
limiter to protect the oven and load
· Protective gas connection to purge with non-flammable protective or reaction
gases, not gas tight
· Manual or automatic gas supply system -
Details
These powerful laboratory muffle furnaces are available for temperatures up to 1400 °C, 1500 °C, 1550 °C or 1600 °C. The durability of the SiC rods in
periodic use, in combination with their high heating speed, make these high-temperature furnaces to all-rounders in the laboratory. Heating times of
20 – 25 minutes to 1400 °C can be achieved, depending on the furnace model and the conditions of use.Standard Equipment
· Tmax 1400 °C, 1500 °C, 1550 °C or 1600 °C
· Working temperature 1500 °C (for high-temperature furnaces LHTC ../16),
increased wear and tear must be expected in case of working at higher
temperatures
· Optional flap door (LHTC) which can be used as work platform or lift door
(LHTCT) with hot surface facing away from the operator (High-temperature
furnace LHTCT 01/16 only with lift door)
· Switching system with solid-state-relays, power tuned to the SiC rods
· Easy replacement of heating rods
· Adjustable air inlet opening, exhaust air opening in the roof
· Controller C450 (10 programs with each 20 segments), alternative controllersAdditional Equipment
· Over-temperature limiter with adjustable cutout temperature as temperature
limiter to protect the oven and load
· Protective gas connection to purge with non-flammable protective or reaction
gases, not gas tight
· Manual or automatic gas supply system
-
Details
We offer for sale a Ηaier DW-86L388 ULT -86°C Freezer
Advanced refrigeration provides reliability and superior performance- Faster temperature recovery with 20% more heat removal capacity
- More energy efficient, using 15% less power
Has built in alarm system.
Tested from our technical team. In excellent working condition.
Key Features
Reliable Performance
Energy Saving
Slim DesignManual of the device can be found : Here
-
Details
We offer for sale a Thermo Scientific Model 907 -86°C 28 cu ft Freezer
Advanced refrigeration provides reliability and superior performance- Faster temperature recovery with 20% more heat removal capacity
- More energy efficient, using 15% less power
Has built in alarm system.
Tested from our technical team. In excellent working condition.
Manual of the device can be found : Here
-
Details
We offer for sale a Dionex TC-1 ICS-3000 Chromatography Thermal Compartment Column.
Tested from our technical team.
Manual can be found here:https://pdfhost.io/edit?doc=926baea6-4570-49a3-8282-08f397c045bb
-
Details
Our company Scientific Instruments is specialized on the sale and service of refurbished analytical instruments of all Big brand names.
Available for sale :
- Dansensor Map Check 3 O2 Gas Save
This instrument is available for viewing at our Test – laboratory. Available also installation and training services.This instrument is sligtly used, performance check has been done and its in excellent condition.
Suitable for :
- Gas check in modified atmosphere
-
Details
GFL 1083 Shaking Water bath
In good working condition tested from our service team.
-
Details
Our company Scientific Instruments is specialized on the sale and service of refurbished analytical instruments of all Big brand names.
Available for sale :
- Dansensor Map Check 3 O2+CO2 Gas Save
This instrument is available for viewing at our Test – laboratory. Available also installation and training services.This instrument is sligtly used, performance check has been done and its in excellent condition.
Suitable for :
- Gas check in modified atmosphere
-
Details
THIS REFURBISHED PERKIN PERKIN ELMER AUTOSYSTEM SYSTEM GC IS TESTED AND FOUND TO BE WORKING PERFECLTY. IT HAS BEEN RECONDITIONED AND FULLY TESTED WITH CALIBRATION TEST MIX.
DETECTOR FID
Computer with Win 7 and pre-installed TotalChrom Software
Mouse, Keyboard and Monitor 22″
Please contact us for more information. Should you have any question please do not hesitate to contact us.
SHIPPING & HANDLING
We will ship it by freight service.
Lead time:10 business days.
International shipping cost will be estimated. Please contact us for the shipping quote.
TERMS AND CONDITIONS
3 months warranty for the Instrument
-
Details
This Refurbished Waters 2695 Separation Modules Liquid Chromatography system HPLC has been reconditioned and fully tested with calibration test mix.
THIS ITEM COMES WITH THE FOLLOWING:
Waters 2695 HPLCWaters 996 Photodiode Array Detector
Column Heater
Computer with pre-installed EMpower Software + Bus Lace Card
Mouse, Keyboard and Monitor
Connection Cables, Power cord and manuals
Please contact us for more information. Should you have any question please do not hesitate to contact us.
SHIPPING & HANDLING
We will ship it by freight service.Lead time:10 business days.
International shipping cost will be estimated. Please contact us for the shipping quote.
TERMS AND CONDITIONS
HAPPY CUSTOMERS
Scientific Instruments operates a Premier Vacuum Pump Repair Center for all the well-established brands with competitive pricing and the assurance that the job will be done properly.
We use only genuine […]
Our service team is consisting of experienced Service engineers and Application specialists. We operate worldwild covering a variety of fields. Our great experience is the key to our successful operation. […]
Our special trained team manufactures Special Gas Chromatography Gas Analyzers for Gas, Petrochemical Industry etc. We manufacture and test analyzers like LPG, RGA, NGA, TOGA and any kind of analyzer […]
